Camper Van High Powered Electrical System
Capabilities
400-600Ah Battery Bank
3000W Inverter
up to 700W Solar Input
Benefits
Large battery bank
Dual alternator charger units for up to 60A of charging while driving
Inverter Charger to generate AC power and Charge from shore power
Install Video
Parts List
Disclaimer: This page includes affiliate links, and I’d really appreciate it if you used them! By purchasing items through my affiliate links, you help me continue to create and serve content. Thanks!
Note: the prices listed below were updated in May of 2024 but prices may fluctuate with time. Nonetheless, I thought it would be helpful to give the price along with the parts list to serve as an estimated material cost for the system. Also note that the most significant cost driver is the batteries. To reduce cost, shop around for different battery options or deals available.
Parts List | ||||
|---|---|---|---|---|
| Item | Link | Quantity | Unit Price | Total Price |
| Storage | ||||
| Batteries | 4 | $925 | $3700 | |
| Monitor | 1 | $158.95 | $158.95 | |
| Cutoff switch | 1 | $38.35 | $38.35 | |
| Main Fuse | 1 | $51.06 | $51.06 | |
| 1 | $24.86 | $24.86 | ||
| DC Bus Bar | 1 | $201.45 | $201.45 | |
| 2 | $9.99 | $19.98 | ||
| 2 | $9.8 | $19.6 | ||
| Solar | ||||
| Solar Panels | 3 | $73.99 | $221.97 | |
| Entry Gland | 1 | $9.99 | $9.99 | |
| Breaker/Disconnect | 1 | $24.99 | $24.99 | |
| Charge Controller | 1 | $184.45 | $184.45 | |
| Alternator | ||||
| Charge Controller | 2 | $205.18 | $410.36 | |
| Fuse Holder | 1 | $24.98 | $24.98 | |
| 1 | $20.73 | $20.73 | ||
| 1 | $16.95 | $16.95 | ||
| AC Loads | ||||
| Inverter Charger | 1 | $1168.75 | $1168.75 | |
| 1 | $117.3 | $117.3 | ||
| 1 | $16.15 | $16.15 | ||
| AC Input Breaker | 1 | $95.59 | $95.59 | |
| Shore Power Inlet | 1 | $22.99 | $22.99 | |
| Distribution | ||||
| Distribution Panel | 1 | $98.01 | $98.01 | |
| DC Fuses | 1 | $8.99 | $8.99 | |
| AC Breaker | 1 | $ | $ | |
| AC Breaker | $ | $ | ||
| Cabling | ||||
| 1 | $214.56 | $214.56 | ||
| 1 | $113.15 | $113.15 | ||
| 1 | $57.87 | $57.87 | ||
| 1 | $39.94 | $39.94 | ||
| 1 | $30.99 | $30.99 | ||
| 1 | $ | $ | ||
| Connectors | ||||
| 1 | $46.13 | $46.13 | ||
| 1 | $22.72 | $22.72 | ||
| 1 | $10.86 | $10.86 | ||
| 2 | $6.1 | $12.2 | ||
| 1 | $8.99 | $8.99 | ||
| 1 | $8.99 | $8.99 | ||
| 1 | $12.89 | $12.89 | ||
| Total Price | $7213.86 |
